TN4060 CO2 Laser Engraver Cutter For Nonmetal Wood MDF Acrylic Leather

Model:TN4060

WorkingArea:600mm*400mm/23.62in*15.75in

Laser Power: 40w 50w 60w 80w 100w 130w 150w and more

Tube: Glass tube or Metal tube.
Worktable: Honeycomb, Metal slate, up and down
Other Optional: Red dot pointer, rotary device with clips or roller

这里可以自定义设置

TN4060 CO2 LASER

CUTTING MACHINE

Cutting and Engraivng Solutions of Wood, MDF,

Acrylic, Cloth, Leather, Double color sheet, Other nonmetal materials.

Fast Speed, Smooth Cutting Effect, High Efficiency

Machine Videos

TRANSON TN4060 CNC co2 laser engraver cutter has both cutting and engraving functions. Laser engraver cutter have the advantage of high precision, fast speed, smooth cutting edge,good stability. It can be widely applied to laser engraving and cutting of almost all nonmetal materials. Include paper, leather, fabric, wood, bamboo, acrylic, MDF, plywood, etc.The standard 60W power mainly suggest for engrave work and cut work of thin material. If you want cut thick material, can change to big power laser tubes like 80W, 100W, 120W. This TN4060 is a hot and small CNC laser cutter, many customer use as wood laser cutter, acrylic laser cutter, MDF laser cutter.

TN4060 co2 laser machine

TN4060 laser machine engrave cut 5mm acrylic

Parameter

Transon CNC TN Cabinet Models Co2 Laser Machine
Model	TN4060	TN6090	TN1290	TN1390	TN1490	TN1610
Working Area	*600mm400mm/ 23.62in15.75in*	900mm600mm /35.43in23.62in	1200mm900mm /47.24in35.43in	1300mm900mm/51.18in35.43in	1400mm900mm/ 55.12in35.43in	1600mm1000mm /63in39.37in
Laser Power	40w/60w/90w/100w	90w/100w/120w150w/180w
Laser Type	CO2
Worktable	Metal slat/Honeycomb (standard with one)
Engraving Speed	0-70000mm/min
Cutting Speed	0-40000mm/min
Highest Scanning Precision	2500DPI
Power Requirement	110V220V,50HZ/60HZ
Min. Shaping Character	English 1.0 x 1.0mm, Chinese 1.5 x 1.5mm
Graphic Format. Supported	BMP, PLT, DST, DXF, Al
Software Supported	Coreldraw, Photoshop, AutoCAD, TAJIMA
Control System	Ruida brand
Machine Work Software	Rdworks
Laser Output Control	1-100% by setting in the software
Interface	USB
Driving System	Stepper
Color Separation	Yes
Optional Part	Upand down worktable/Another worktable/Red dot poiner/Auto focus/Rotary attachment with roler/ Rotary atachment with roller/Rotary attachment with clip
Spare Parts	Extra laser tube/Extra 1 lens and 3 mirrors

PRODUCT DETAILS

Observation windown design

The worktable cover is installed transparent tempered glass.

Linear guider

Square sharp linear guider, small resistance, smooth sliding, low noise, good balance performance.

Laser head

With high quality metal reflector and focus lens , as well as red dot pointer,it makes the working speed faster,precision higher.

60w CO2 laser tube

Cl series: estimate 3000 hours life span,360days warranty

Laser power supply

Constant laser power supply to laser tube, with exhaust fan.

Core control system

Adopting China top brand Ruida laser control card, reasonable wiring can reduce electromagnetic interference and enhance the stability of machine operation.

Control panel

LCD digital control panel with USB interface, support offline work.

Emergency stop button & Key switch.

Water pump

Suggest for cooling 40W 60W laser tube.

Socket

Multi-function socket at the back of the machine.

Metal slat worktable

Metal slat worktable can meet the flatness requirment of hard materials, like wood, acrylic, etc.

Honeycomb worktable

Makes the board more solid and more flat.It’s suitable for engraving work and also good at cutting leather and other soft materials. （Note:one worktable standard with machine: Metal slat / Honeycomb）

Exhaust fan

Heat dissipation is fast, can extend the life of machine.

Air pump

Air pump can keep forcus lens clean and cool the laser head.

Full-direction Wheel & position leg

It can help move and fix the laser machine easily.

Tool box

Tools for maintaining the machine are included.

Three mirrors and one lens

High quality reflection mirrors and focus lens, high efficiency and stable performance.

OPTIONAL PARTS：

Up and down worktable

Making worktable move up and suitable for processing materials in different thickness.

Red dot pointer & Auto focus

Red dot pointer makes laser beam visible,so adjustment of laser beam would be much easier. Auto focus can set the optimal focus according to thickness of objects automatically.
(They need work together with up and down worktable).

Worktable

Honeycomb / Metal slat/
High density metal slat worktable is used for leather, cloth and small parts cutting, the distance between two metal slat will less than 2cm.

Rotary device with roller

For heavy and fragile round materials’ engraving,such as glass cup,bottle, etc. It should work together with up and down worktable.

Rotary device with chuck

For round materials’ engraving,such as wood,etc. It should work together with up and down worktable.

APPLICATION

Applicable industries:
Model industry (construction models, aviation and navigation models and wooden toys), advertising, decoreation, arts and crafts, electronics and electric appliances, etc.

Applicable Materials:
Double color sheet, acrylic, glass, wood, mdf, bamboo ware, coconut shells, paper, leather, cloth, marble, ceramic tile, shells and other nonmetal materials.

PACKAGING & DELIVERY

Model	Laser Power	*Machine size LWH(m)**	*Package Size LWH(m)**	Volume (cbm)	Net Weight	Gross Weight(kg)
TN4060	40w	1.060.811.05	1.20.911.2	1.31	180	220
	60w	1.360.811.05	1.460.911.2	1.59	190	230
	90w	1.360.811.05	1.460.911.2	1.59	200	240
	100w	1.560.811.05	1.680.911.2	1.83	210	250
TN6090	75-100w (W1 / W2)	1.361.011.05	1.511.131.2	2.05	220	280
	100-120w (W4)	1.611.011.05	1.681.131.2	2.28	250	320
	130-150w (W6)	1.811.011.05	1.911.121.2	2.57	260	340
	150-180w (W8)	2.01.011.05	2.11.121.2	2.82	280	360
TN1290	75-120w (W1/ W2/W4)	1.661.311.05	1.781.431.25	3.18	350	420
	130-150w (W6)	1.811.311.05	1.981.411.25	3.49	370	450
	150-180w (W8)	2.01.311.05	2.11.411.25	3.7	380	460
TN1390	75-150w (W1/W2/W4/W6)	1.761.311.05	1.901.441.29	3.5	380	466
TN1390	150-180w(W8)	1.981.311.05	2.11.411.25	3.7	385	465
TN1490	75-150w (W1/W2/W4/W6)	1.861.311.05	1.971.411.25	3.47	360	440
TN1490	150-180w(W8)	2.01.311.05	2.11.411.25	3.7	390	470
TN1610	75-180w (W1/W2/W4/W6/W8)	2.061.411.05	2.171.511.25	4.1	370	450
Above packing information for Reci brand laser tube just for reference, any add or change of components may differ changes.
We will measure each package's size and weight before shipping.
