Mixed Metal And Nonmetal Co2 Laser Cutter Tsh1530

Mixed Metal And Nonmetal CO2 Laser Cutter 1530

Model:TSH1530

Working Area: 1500mm*3000mm/59.1in*118.11in

Laser Power: 100w 130w 150w 180w 260w 300w 350w
Tube: Glass tube or Metal tube.
Worktable: Honeycomb, Metal slate, up and down
Other Optional: Red dot pointer, rotary device with clips or roller

这里可以自定义设置

Mixed Metal And Nonmetal

CO2 Laser Cutter TSH1530

Cutting Solutions of

Stainless steel,carbon steel,wood, acrylic and so on.

Fast Speed, Smooth Cutting Effect, High Efficiency

Machine Videos

This TSH1530 model mixed co2 laser cutting engraving machine suit for cut work of thin metal sheet include stainless steel and carbon steel.

It can also do engrave and cut work for almost all nonmetal material include acrylic, wood, leather, plywood, MDF, fabric, etc.

TSH1530 co2 mixed laser cutter machine

co2 mixed laser cutter cut stainless steel tube

10mm MDF 15 speed, 85% power

mixed laser cutter cut stainless steel

Parameter

Transon Metal And Nonmetal Laser Cutting Machine
Model	TSH1390/TSH1325/TSH1530
Working area	1300mm900mm /51.18in35.43in, 1300mm2500mm/51.18in98.43in, *1500mm3000mm/59.1in118.11in*
Laser power	150W180W280W300W
Laser type	CO2 sealed laser tube, water-cooled, 10. 6umWater Cooling
Cooling Type	CO2 sealed laser tube, water-cooled, 10. 6umWater Cooling
Cutting speed	20m/min
Laser output	1-100%software setting
Positioning accuracy	≤±0.01mm
Power supply	AC 110/220V±10%，50HZ/60HZ
Operating temperature	0-45°C
Operating humidity	5-95%
Smallest shaping character	Chinese: 2. 0mm x 2.0mm, English 1.0mm x 1.0mm
Graphic format supported	BMP, PLT, DST, DXF, AI
Software supported	Tajima, Corel Draw, Photoshop, Auto CAD
Driving system	Stepper
Color separation	Yes

Note:
When cutting thin metal (stainless steel and carbon steel), oxygen assistance is required
When cutting nonmetal, air assistance is required.

PRODUCT DETAILS

Dust cover

It used for protecting linera guider and belt.

Linear guider

Square sharp linear guider, small resistance, smooth sliding, low noise, good balance performance.

Laser head

A special laser head that can cut both metal and nonmetal.

Laser tube

Optional laser power: 150w/180w/280w/300w

Laser power supply

Constant laser power supply to laser tube, with exhaust fan.

Core control system

Adopting China top brand Ruida laser control card, reasonable wiring can reduce electromagnetic interference and enhance the stability of machine operation.

Control panel

LCD digital control panel with USB interface, support offline work.

Emergency stop button & Key switch.

CW5200 water chiller

CW5200 water chiller with water temperature display and alarm system can avoid over burning, keep water circulation successful.

Socket

Multi-function socket at the back of the machine.

Metal slat worktable

Metal slat worktable can meet the flatness requirment of hard materials, like wood, acrylic, etc.

Touch screen

Exhaust fan

Heat dissipation is fast, can extend the life of machine.

Air pump

Air pump can keep forcus lens clean and cool the laser head.

Full-direction Wheel & position leg

It can help move and fix the laser machine easily.

Free tool box

Tools for maintaining the machine are included.

Three mirrors and one lens

High quality reflection mirrors and focus lens, high efficiency and stable performance.

APPLICATION

Applicable industries:
Model industry (construction models, aviation and navigation models and wooden toys), advertising, decoreation, arts and crafts, electronics and electric appliances, etc.

Applicable Materials:
Stainless steel,carbon steel,mild steel,wood,acrylic,double color sheet and other nonmetal materials.
