20w 30w Fiber Laser Marking Machine super Mini Type Desktop fiber laser engraver
Power: 20w 30w
Repeatability Accuracy: ±0.001mm
Marking Range:110*110mm standard (others optional)
Rotary Device: Optional
E-mail: sales@transoncnc.com Mobile: +86 18653117691 (whatsapp)
Professional cnc laser and cnc router factory since 2010
20w 30w Fiber Laser Marking Machine super Mini Type Desktop fiber laser engraver
Power: 20w 30w
Repeatability Accuracy: ±0.001mm
Marking Range:110*110mm standard (others optional)
Rotary Device: Optional
Machine Videos
写点什么 ...
Machine Videos
Laser engraving equipment can do quickly and permanently mark of text, picture, serial numbers, bar codes, QR code, etc. for all metal material and part nonmetal material. It mainly use for mark on tools, metal parts, jewelry, firearms and industry polymers. Can be use as laser label maker, laser name plate maker, infrared laser marker, etc.
Parameter
Model | TSF-20 E | TSF-30 E | |
Laser Power | 20w | 30w | |
Laser Wavelength | 1064nm | ||
Q-frequency | 30-60KHZ | 40-60khz | |
Maximum single pulse energy | 0.67mJ | 0.75mJ | |
Marking Range | 110*110mm standard (others optional) | ||
Minimum Line Width | 0.02mm | ||
Minimum Character | 0.15mm | ||
Marking Depth | 0 ~0.5mm | ||
Repeatability Accuracy | ±0.001mm | ||
Beam Quality | M2<1.5 | M2<1.6 | |
Marking Format | Graphics | ||
Marking Format | Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date,Batchnumber,Serialnumber,Frequency,etc. | ||
Graphic Format Supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. | ||
Working Voltage | 220V±10%/50Hz/4A | ||
Unit Power | <0.5kw | ||
Package size | 620*420*420mm | ||
Gross Weight | 30kg |
PRODUCT DETAILS
APPLICATION
Applicable Industries
Mobile phone keypad, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.
Applicable Materials
Metals (steel, titanium, copper, gold, silver, including rare metals), engineering plastics, electroplating materials, coating materials, plastics, rubber, epoxy resin, ceramic, ABS, PVC, PES and other materials.
PACKAGING & DELIVERY
Trade Terms: EXW, FOB, CNF, CIF, DDU, DDP, etc.
Supply Ability: 100 sets / Month
Port: Qingdao
Payment: T/T (Bank Transfer), western union, moneygram, PAYPAL payments for offline orders.
Packaging Detail: International standard plywood export box
Shipping: BY SEA, BY LAND, BY AIR OR BY EXPRESS
OUR SERVICE
Jinan Transon CNC Equipment Co., Ltd is an integrated CNC automation equipment manufacturer in Jinan China found in 2010.
Please leave your message with contact information,we will reply you as soon as possible,also we can offer the customized machine,please feel free to discuss about your idea.
