CNC engraving machine system software design

Due to the ARM processor in the system mainly ACTS as a helper, concrete is based on the inside of the dual port RAM data, the data is simple, the processing of sent PCL6045 corresponding control instruction, complete the whole carving work, ARM processor to capture the scene at the same time, according to the collected data to determine whether a carving machine work is normal, PCL6045 inside there are a lot of register is used to control movement, such as speed, movement patterns, etc. , in writing the program, only need to operate these registers.
STM32F103ZET6 this processor peripherals quite rich, so its various registers are very much, also ST company in order to facilitate users to use this series CPU, the production to the operation of the CPU peripherals into a library, the user when the application is written, only need to call the Treasury of the corresponding function can operate it easily CPU peripheral resources, ningbo sea CNC engraving machine co. , LTD. Design of the system adopts the ST's 3. 3. 0 version of the standard peripherals library for software design, development environment using the Keil MDK integrated compiler of the company.
