Universal CO2 Laser Engraving System on Most Non-metal Material

这里可以自定义设置
Universal CO2 Laser Engraving System on Most Non-metal Material
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Application:
Laser Engraving
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, Plastic, Plexiglax, Plywood, Rubber, Stone, Wood, fabric,cloth etc
Engraving Area:
1600*1000mm
Laser Type:
CO2
Engraving Speed:
0-70000mm/s
Graphic Format Supported:
AI, PLT, DXF, BMP, Dst
Condition:
New
CNC or Not:
Yes
Cooling Mode:
WATER COOLING
Place of Origin:
Shandong, China
Brand Name:
Transon
Dimension(L*W*H):
2.16*1.41*1.07m
Certification:
ce, ISO, GS, UL, CCC, FDA
Laser Source Brand:
other
Key Selling Points:
High Productivity
Warranty:
1 Year
After-sales Service Provided:
Video technical support, Engineers available to service machinery overseas
Applicable Industries:
Machinery Repair Shops
laser power:
80W
laser type:
Sealed CO2 laser tube ,water-cooling ,10.6um
working area:
1600*1000mm
Cooling type:
water cooling
engraving scanning Speed:
0-70000mm/min or 0-2756in/min
laser output control:
1-100% software setting
supported Graphic Format:
PLT,AL,BMP,DST,DXF
Compatible Software:
Coreldraw photoshop,Autocad,Tajima,All types of CAD software in cloth
locating Precision:
<=+-0.01mm
Supply Ability
Supply Ability:
500 Set/Sets per Month

 TransonCo2  laser engraving cutting machine TS1610



Welcome to contact Transon laser by leaving a message below or send inquiry to linda(at)transoncnc.com for further information.Your kind response of below questions will help us to recomemnd the most suitable model to you asap.
1,Are you looking for laser cutting machine or laser engraving machine?
2,Which material need to cut or engrave ?
3,What is the thickness and size of materials?
4,What is your business industry?





Feature

1.Honeycomb and aluminous strip panel double-face working table is suitable for processing different kinds of materials.
2.Automatic up and down working table, easy and flexible operation.
3.Equipped with Ultrasonic Auto-focus System to meet different processing demand.
4.Humanism closed designed system for top and bottom exhaust, ensures the safety of the processing, worriless whole-process.
5.Equipped Rotary attachment for engraving cylindrical objects.



Video

Acrylic laser cutter video: http://youtu.be/UqQPColPL-8

Wood laser engraver cutter video: http://youtu.be/6j_jTUwjymk

Leather laser engraver cutter video: http://youtu.be/4m4zSmo2rQQ

MDF laser cutter video: http://youtu.be/bfaPLfZJ3W0







sample

Shipment

The machine will be shipped by sea,pls kindly tell me the nearest discharge port for you.

For some small machine,it can be shipped by air and courier shipment.

To Russia,it can be shipped by sea and by ground.



Applicable
Acrylic | Plexiglass | Pmma| Perspex | PP Plastic
Double color plate | Organic board
Wood | Bamboo | Veneer | MDF
Leather |Pig leather |Cow Leather |sheep leather
Fabric |Cloth | Textile | Wool Felt
Paper | Cardboard | Chipboard|Press Boardface engraving on add material as follow
Ceramic | Tile| Marble
Fiber glass
If your material is not on the above, please kindly contact us to confirm!







Feature

1.CO2 Glass sealed laser tube(China made famous brand)
Good beam mode and stability,laser power can make 40% higher than the general laser tube,service time over 10000 hours.
2.Imported of II-VI ZnSe focusing lens high transmittance, good focusing effect and stability
3.DSP control system
USB interface,support online/offline work,flash drive offline direct reading, with Chinese and English language system setup, cutting speed and power can adjustable easily, improve work efficiency
4.straight double guide rails( Imported famous brand )Make the machine with high precision
5.Stepping motor drive and belt transmission
6.three-phase stepper motor driver with good stability and high precision
7.Industrial Cooling System(CW 3000 for 60W 80W laser tube, CW 5200 for 100W )
No water scale during the laser machine working, ensure the constant water temperature, which can make the laser tube a longer service time and high stability.
8.The alarm device,China first fire warning device in laser machines, avoid the property damage caused by fire.
9.Honeycomb or Slatted worktable optional
Honey comb worktable for cutting fabric, leather and other soft material
Aluminum knife worktable for cutting acrylic and other hard material.
10.Routeway feeding----allow users of roll material with unlimited length
11.Optional up & down adjustable worktable---Can engrave & cut different height materials.
12.Hydraulic protection, exhaust dust and smoke device, the huff protection
13.Reinforced and Coated plastic treatment machine body: firm and anti rust
14.Strong Software
Lasercut5.3 software, easy operation
The proprietary software which supports the output of various files format : PLT, BMP ,DXF,DST, T100 etc



Parameter



 Standard

optional



Detail picture



Guarantee

One year guarantee for whole machine except of laser tube and lens

24 hours technical support by e-mail, calling or door-to-door service

English software, user manual and detailed Videos CD





More model







Factory



The product has many good characteristics and caters to the varied demands of our clients, showing a wide use in the future. It is granted with certifications such as CE and FDA. The product is going to expand market further as we keep product improvement. It is granted with certifications such as CE and FDA.
