TN6090 CO2 laser Engraving Cutting Machine with Davi 70w Metal RF Laser Tube

这里可以自定义设置
TN6090 CO2 laser Engraving Cutting Machine with Davi 70w Metal RF Laser Tube
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Application:
Laser Engraving
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, Plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Laser Type:
CO2
Engraving Speed:
0-60000mm/min
Graphic Format Supported:
AI, BMP, Dst, DXF, PLT
Condition:
New
CNC or Not:
Yes
Cooling Mode:
Air Cooling
Place of Origin:
Shandong, China
Brand Name:
Transon
Model Number:
TN6090
Dimension(L*W*H):
1.46x1.12x1.31mm
Certification:
ce, ISO, FDA
Laser power:
60W
Tube type:
RF tube
Function:
Cutting Engraving Non-metal Materials
Color:
Red-black
After-sales Service Provided:
Engineers available to service machinery overseas
Engraving Area:
900*600mm
Supply Ability
Supply Ability:
300 Set/Sets per Month

TN6090 CO2 laser Engraving Cutting Machine with Davi 70w Metal RF Laser Tube



Features:

1. China famous Davi 70w air cooling metal laser tube, the gas can be refilled.

2. Lifespan is 25000--40000 hours.
3. Working precision is higher than co2 glass laser tube.
4. Smooth cutting edge.
5. Air Assist, remove heat and combustible gases from the cutting surface.
6. Adjustable speed and power.
7. Reinforced and thickened machine body.



Small letter engraved on acrylic:



Parameters:

Model

TN6090

Working area

600mm*900mm

Laser power

Davi 70W RF metal tube

Laser type

CO2 RF metal laser tube, air-cooled

Worktable

Standard with metal slat worktable

Engraving speed

0-70000mm/min

Cutting speed

0-40000mm/min

Highest scanning precision

2500DPI

Power supply

110v/220v,50Hz/60Hz

Min. shaping character

English 1.0 x 1.0mm, Chinese 1.5 x 1.5mm

Graphic.format.supported

BMP, PLT, DST, DXF, AI

Software supported

CorelDraw, PhotoShop, AutoCAD,TAJIMA

Control system

High speed DSP control system brand Ruida

Machine work software

RDWorks V8 (Ruida)

Laser output control

1-100% by setting in the software

Interface

USB

Driving system

Stepper motor or China Servo motor

Can choose

Multi-function protect power supply

Color separation

Yes







Packing& Delivery



The operators will encounter less fatigue and tiredness with this product, which allows them to focus on more professional things. This product is able to help the worker in performing his or her duties in a better way than by hands.
