Russia hot sale!! small router cnc machine 6090

这里可以自定义设置
Russia hot sale!! small router cnc machine 6090
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Place of Origin:
Shandong, China
Brand Name:
Transon
Voltage:
220V
Dimension(L*W*H):
1300*900*1400mm
Certification:
CE
Warranty:
1 Year
After-sales Service Provided:
Field maintenance and repair service
working area:
600*900mm
removing way:
ganry moving
transmit way:
gear wheel
applications:
woodworking field and other
spindle power:
1.5Kw
machine power:
450kw
max speed:
10m/min
working speed:
3.5m/min
cutting diameter:
3.175-6mm
spindle rotating speed:
0-24000rpm
Power:
1500W
Weight:
280
Supply Ability
Supply Ability:
500 Set/Sets per Month

Russia hot sale!! small router cnc machine 6090



worksize:1200*2400mm,1200*1800mm,1200*1200mm,900*1500mm,600*1500mm,600*900mm

Spindle:1500W/2200W/3000W







Welcome to visit our website. I'm wendy and my email address is linda(at)transoncnc.com. I know you are interesed in this product, if you have any questions, please let me know. We provide high quality products, excellent services,competitive prices and prompt delivery.



Features of mini cnc router

CNC router is one high precision small CNC engraver with 2D& 3D CAD/CAM machining capabilities.

It is the best choice for the Engraver,Sign maker,Panel maker and Educational Institution.

The machine structures are designed with cast steel and  with Germany ball screws transmission for x, y & z axes.

 It is small enough to fit into almost any work space.



Application of mini cnc router:

Strong functions,easy operation,sturdy,realiable performance,rich functions,wide application;can be used to process and make any woody products,

sign products,bill plates,chest brands,seals,metal foil moulds,constrction models,instrument panel and industrial moulds or non-metal materials,for example,iron,copper,aluminum,

plastic plates,wood plate,etc.



Machine parameter



X,Y,Z Working Area

600x900x150mm

X,Y,Z Traveling Positioning Accurary

±0.03/300mm

X,Y,Z repositioning Positioning Accurary

±0.02mm

Table Surface

T-slot Extrusions

Frame

Welding steed

X, Z Structure

Ball Screw

Y Structure

Hiwin Rail Linear Bearings and Ball Screw

Max. power Consumption

2.2Kw

Max. Rapid Travel Rate

8000mm/min

Max. Working Speed

6000mm/min

Spindle Power Motor

1.5Kw self cooling spindle

Spindle Speed

0-24000RPM

Drive Motors

Stepper system

Working Voltage

AC220V/50/60Hz

Command Language

G code

Operating System

DSP System (Option:Mach3 PC Software)

Interface

USB

Flash Memory

128M(U Disk)

Collet

ER16

X,Y Resolution

<0.01mm

Software Compatibility

Type3 software,(Option: Artcam software)

Running Environment

Temperature: 0°C~45°C ,Relative humidity: 30%~75%

Package

Plywood box



Guarantee & After Sales Service:
1) The machine guarantee is 18 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.



Machine stardard parts









Company





Clients show











Contact information









The product is safe and secure for people during operation. People can rest assured that potential safety hazards are not possible to occur. It can be designed to be wireless using wireless technology. The product requires a low number of workers to execute production tasks, which will help reduce labor costs and help manufacturers achieve a competitive advantage. It can be designed to be wireless using wireless technology.
