Mini Handhold Metal Fiber Laser Marking Machine 30w

Overview

Quick Details

Application:: Laser Marking

Working Accuracy:: 0.01

Graphic Format Supported:: AI, PLT, DXF, Dst

Laser Type:: Fiber Laser

Condition:: New

CNC or Not:: Yes

Cooling Mode:: Air Cooling

Control Software:: EZCAD

Place of Origin:: Shandong, China

Brand Name:: Transon

Certification:: ce

Laser Source Brand:: RECI

Control System Brand:: EZCAD

Weight (KG):: 70 KG

Key Selling Points:: Competitive Price

Warranty:: 2 years, 3 years

After-sales Service Provided:: Online support, Video technical support

Applicable Industries:: Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Printing Shops, Construction works , Food & Beverage Shops

After Warranty Service:: Video technical support, Online support

Local Service Location:: Turkey, United Kingdom, Philippines, Peru, Pakistan, Russia, Romania

Showroom Location:: Turkey, United Kingdom, Philippines, Peru, Pakistan, Russia, Romania

Marking Area:: 110mm*110mm

Machinery Test Report:: Provided

Video outgoing-inspection:: Provided

Marketing Type:: Hot Product 2019

Warranty of core components:: 1 Year

Core Components:: PLC

Product name:: Mini Handhold Metal Fiber Laser Marking Machine 30W

Marking Speed:: ≤7000mm/s

Laser Souce:: Raucus

Laser Head:: Galvonometer head

Marking Depth:: 0.01-1mm

Lifespan of Laser Device:: 100,000 hours

Laser Wavelength:: 1064nm

Marking Format:: Graphics, Text, Bar Codes, QR Code, Serial Number,Serial number,etc.

Voltable:: 110V/220V

Packaging & Delivery

Selling Units:: Single item

Single package size:: 177X141X135 cm

Single gross weight:: 420.000 kg

Package Type:: International standard package for Transon CO2 Laser Engraving Cutting Machine.

Picture Example:

Lead Time :

Quantity(Sets)	1 - 1	>1
Est. Time(days)	15	To be negotiated

Product Description

Fiber laser marking machine can do quickly and permanently mark of text, picture, serial numbers, bar codes, QR code, etc. for all metal material and part nonmetal material. It mainly use for mark on tools, metal parts, jewelry, firearms and industry polymers.
Fiber laser marking machine can have some cutting ability by mark many times, if want for some cut work of thin metal sheet like silver, aluminum, brass, gold 1mm thickness.Widely used in integrated circuit chips, computer accessories, industrial bearings, electronic and communication products.Military things graphics and text markup, mass production line and homework.Feature:1.Fast marking and high efficiency. 2.Long life: The metal laser marking machine can work continuously in harsh working environments, and the laser is free of maintenance for 100,000 hours. 3.Compact, small, easy to operate 4.Suitable for industrial application

Product details

Raycus Fiber Laser Source

Hot sale Raycus brand fiber laser source, with 100,000 hours life span and 3 years warranty. Each fiber laser source standard with test report. Optional: MAX, JPT, IPG brand, JPT MOPA colorful mark fiber laser source. PS:this price is for Raycus 20w.

SINO High Speed Galvanometer

High speed SINO scan head, scan head with on off button for out red dot pointer. Scan head inner with one inner red dot pointer for user easy preview marking content on worktable.

Wavelength Brand Field Lens

machine standard with 110x110mm marking area Wavelength brand field lens. But users can buy extra field lens for bigger area mark.
Like 150x150mm, 175x175mm, 200x200mm, 300x300mm, 400x400mm. We will calibrate and recored the paramters for each field lens for
our users.

EZCAD Software

Machine with EZCAD software, it compatible with other software like Photoshop, AUTOCAD, Coreldraw,
users can use these softwares to make design then import the file to EZCAD to mark. The files EZCAD support: AI, PLT,DXF,DST,SVG,JPC,NC,G,BOT,GBR, BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF.

Hand Lifting

High-quality materials, high positioning accuracy, stable andconvenient.

Original BJJCZ Control Card

This advanced original BJJCZ control system, support add rotary device to laser marking machine.

Specification

item	value
Application	laser marking
Working Accuracy	0.01
Graphic Format Supported	AI, PLT, DXF, dst
Laser Type	Fiber Laser
Condition	New
CNC or Not	YES
Cooling Mode	AIR COOLING
Control Software	EZCAD
Place of Origin	China
	Shandong
Brand Name	Transon
Certification	ce
Laser Source Brand	RECI
Control System Brand	EZCAD
Weight (KG)	70KG
Key Selling Points	Competitive price
Warranty	2 years
After-sales Service Provided	Online support, Video technical support
Applicable Industries	Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, farms, restaurant, Printing Shops, Construction works , Food & Beverage Shops
After Warranty Service	Video technical support, Online support
Local Service Location	turkey, UNITED KINGDOM, philippines, peru, pakistan, RUSSIA, Romania
Showroom Location	turkey, UNITED KINGDOM, philippines, peru, pakistan, RUSSIA, Romania
Marking Area	110mm*110mm
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Marketing Type	Hot Product 2019
Warranty of core components	1 YEAR
Core Components	PLC
Product name	30W Mini Handheld Fiber Lser Marking Manchine
Marking Speed	≤7000mm/s
Laser Souce	Raucus
Warranty	3 years
Laser Head	Galvonometer head
Marking Depth	0.01-1mm
Lifespan of Laser Device	100,000 hours
Laser Wavelength	1064nm
Marking Format	Graphics, Text, Bar Codes, QR Code, Serial Number,Serial number,etc.
Voltable	110V/220V

Packing & Delivery

Trade Terms: EXW, FOB, CNF, CIF, DDU, DDP, etc.
Supply Ability: 100 sets / Month
Port: Qingdao
Payment: T/T (Bank Transfer), western union, moneygram, PAYPAL payments for offline orders.
Packaging Detail: International standard plywood export box
Shipping: BY SEA, BY LAND, BY AIR OR BY EXPRESS

Application

Applicable

Applicable Industries
Mobile phone keypad, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances,
communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.
Applicable Materials
Metals (steel, titanium, copper, gold, silver, including rare metals), engineering plastics, electroplating materials, coating materials, plastics, rubber, epoxy resin, ceramic, ABS, PVC, PES and other materials.
