Application:

Laser Marking

Working Accuracy:

0.002mm

Graphic Format Supported:

AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT

Laser Type:

Fiber Laser

Condition:

New

CNC or Not:

Yes

Cooling Mode:

Air Cooling

Control Software:

EZCAD

Place of Origin:

Shandong, China

Brand Name:

Transon

Model Number:

TSF

Certification:

ce, ISO, FDA

Beam quality:

M2< 1.5

Laser wavelength:

1064±1 nm

Power adjustment range:

10~100%

Output fiber length:

1~2m

Frequency of pulse:

20~250KHz

Power supply:

220V/60Hz /8A (110V/60Hz /15A can choose)

Working area:

110mm*110 mm(Standard) can choose 150*150mm 200*200mm 300*300mm

Marking depth:

<1mm

Marking speed:

<5000mm/s

Min. line width:

0.05mm

Power:

60W
