Engraving And Cutting Woodworking Machine

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: Transon

Condition:: New

Warranty:: 1 Year

After-sales Service Provided:: Field maintenance and repair service

Product name:: Woodworking machine

Spindle power:: 4.5kw

Spindle speed:: 0-24000rpm

Cooling way:: Water cooling

Transmit way:: Gear Wheel

Fix way:: Vacuum table

Control system:: DSP

Removing way:: Gantry moving

Applications:: Woodworking fields and others

Package:: Plywood box

Supply Ability

Supply Ability:: 15 Set/Sets per Month as per the order

Engraving and Cutting Woodworking machine

Product Description

Features:

·Effective working area: 1300*2500*200mm

· Linear type automatic tool changer with 8 tools

· 9kw Italy HSD ATC air cooling spindle

· 11kw Fuling inverter

· ISO 30 tool holder,can be with tools whose diameter is within 20mm

· Taiwan SYNTEC 6MA / 6MB control system

· 750W Japanese YASKAWA servo motor

· 5.5KW air type vacuum pump

· Dust collector system with two bags

· #25 Taiwan squarelinear guide rail

· Automatic tool sensor calibration; Automatic oil lubrication system

· Vacuum & T-slot working table

Parameters

TRANSON CNC ATC CNC Router
Model	TSW1325ATC
Brand	TRANSON
X,Y Worksize	1300x2500mm
Z-axis Worksize	200mm
Color	Customizable
Control System	TAIWAN SYNTEC
Spindle	9kw HSD ATC air cooling spindle
Inverter	11kw Fuling Inverter
Motor & Driver	750W Japanese YASKAWA
Traveling Speed	60m/min
Working Speed	30m/min
Table	T-slot and vacuum working table with 4 zone
Auto Tool Changer Magazine	Linear With 8 Tools
Transmission	X,Y rack and pinion, Z Taiwan TBI Ball screw
Rail Guide	#25 Taiwan Square Rails
Lubrication System	Automatic
Gantry Structure	Gantry moving
Structure	Industrial class square tube strong structure
Command Code	HPGL, G code
Working Precision	0.05mm
Working Voltage	380V/50HZ, 3 Phase
Vacuum Pump	5.5kw air type vacuum pump (380V, 3 Phases, 50Hz or optional)
Dust Collector	double packet dust collector (380V, 3 Phases, 50Hz or optional)
Tool Sensor	Automatic tool sensor calibration
Machine Size / Packing Size	3.2521.62m /3.362.131.86m
Net Weight/ Gross Weight	1300kg / 1500kg

Product Display

Product Details

Application

Wood furniture industry	Doors; Cabinets; Tables; Chairs. Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
Advertising industry	Signage; Logo; Badges; Display board; Meeting sign board; Billboard Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
Mold industry	Sculpture of copper, aluminum, iron and other metal mold as well as artificial marble, sand , plastic sheeting, PVC pipe and other non-metallic mold.
Artwork and Decoration	wood crafts; gift box; jewelry box
Others	Relief sculpture and 3D engraving and cylindrical object.
