20w portable fiber laser marking machine for engineering plastics

这里可以自定义设置
20w portable fiber laser marking machine for engineering plastics
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Application:
Laser Marking
Working Accuracy:
0.002mm
Graphic Format Supported:
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
Laser Type:
Fiber Laser
Condition:
New
CNC or Not:
Yes
Cooling Mode:
Air Cooling
Control Software:
EZCAD
Place of Origin:
Shandong, China
Brand Name:
Transon
Model Number:
TSF20 Protable Fiber Laser Marking machine
Certification:
ce, ISO, FDA
Marking Area:
50*50mm / 110*110mm/150*150mm/175*175mm/200*200mm\optionals
Marking Speed:
≤7000mm/s
Laser Souce:
IPG/RAYCUS/JPT/MAX/MOPA
Warranty:
2 years
Laser Head:
Galvonometer head
Marking Depth:
0.01-1mm (Depend on materials)
Lifespan of Laser Device:
100,000 hours
Laser Wavelength:
1064nm
Marking Format:
Graphics, Text, Bar Codes, QR Code, Serial Number,Serial number,etc.
Feature:
Free of maintenance
After-sales Service Provided:
Engineers available to service machinery overseas
Power:
20W/30W
Supply Ability
Supply Ability:
300 Set/Sets per Month

20w  protable fiber laser marking machine for engineering plastics

Application



1.Applicable Industries

Mobile phone keypad, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.

2.Applicable Materials

Metals (steel, titanium, copper, gold, silver, including rare metals), engineering plastics, electroplating materials, coating materials, plastics, rubber, epoxy resin, ceramic, ABS, PVC, PES and other materials.



Product Description



Portable fiber laser marking machine is the use of laser beam in a variety of different material surface marked with a permanent mark. Effect of marking is exposed deep substance through the surface material evaporation, showing the required the etching pattern, text, and other types of bar code graphics.

Benefits of Fiber Laser Marking Machine

1).Environmentally friendly: Using no harsh chemicals during the process. No need water chiller to cool, small size small occupation, can be easily installed in many places.

2).Cost-effective: No maintenance during the 100,000 hours working life. One machine can be used in many different materials & industry. Minimal part replacement.

3).High efficiency: Computer operated, suitable for automatically processing(like production line, automatically filling line).

Transon Portable Fiber Laser Marking Machine

Model

TSF

Laser  type

Fiber Laser

Laser  power

20W/30w

Beam  quality

M2< 1.5

Laser  wavelength

1064±1nm

Power  adjustment  range

10~100%

Output  fiber  length

1~2m

Frequency  of  pulse

20~250KHz

Power  supply

220V/60Hz /8A (110V/60Hz /15A can choose)

Cooling  system

Air Cooling

Graphic  format  supported



XML.EPS.CLP.WMF.TIF.CUR.PSD.TGA

Working  area

110mm*110 mm(Standard)

Marking  depth

<1mm

Marking  speed

<7000mm/s

Min. line  width

0.05mm

Repeatability  accuracy

0.003mm

Power  Machine

300W-450W

Operation  temperature

0~40°C

Operation  system

Microsoft Windows 7, 8, 10 system

Operating  environment

Clean and free of dust

Warranty

Two years





Product Display





Product Details





Related Products

Packaging & Shipping





Company Information



Jinan Transon CNC Equipment Co., Ltd is an integrated CNC automation equipment manufacturer with ability of research and development, design and production.Our products include fiber laser marking machine,co2 laser marking machine,co2 laser engraving and cutting machine, cnc router and cnc plasma cutter. These machines have been exported to many countries, such as, United Kingdom, Poland, Hungray, Italy, Netherlands, Romania, United State, Mexico, Brazil, Canada, Australia, Korea, Russia, Peru, Chile and other more than 100 countries. Due to strict control for machine quality and good after-sale service, Transon has won an excellent reputation in the global market.
